10mm Tuda Shockpad

Tuda Shockpad (10mm)

The Tuda Shockpad (10mm) is a high-performance shock-absorbing underlay designed for artificial grass systems. Manufactured from closed-cell PE foam, this product delivers reliable durability, consistent performance, and superior comfort for sports and leisure applications.

Key Features & Benefits

Superior Player Protection – Provides effective shock absorption (27.5%) and vertical deformation (6.7 mm), enhancing player safety.

Durability & Performance – Engineered for long-lasting elasticity, antibacterial resistance, and resistance to corrosion.

Excellent Drainage – With a water infiltration rate exceeding 24,000 mm/h, it guarantees rapid drainage and all-weather playability.

Eco-Friendly – 100% recyclable, odourless, and environmentally safe.

Easy Installation – Supplied in rolls (1.5m width, customizable length), lightweight, and simple to handle on-site.

Technical Specifications

Material: Closed-cell PE foam

Density: 30 ±10% kg/m³ (ISO845)

Thickness: 10 mm

Mass per unit area: 438 g/m² (ISO8543:2020)

Shock Absorption: 27.5% (CEN/TS 16717:2015)

Vertical Deformation: 6.7 mm (CEN/TS 16717:2015)

Water Infiltration Rate: >24,000 mm/h (EN12616:2023)

Tensile Strength: 3.24 kN/m (EN12230:2023)

✔ FIFA Approved
✔ Tested by LABOSPORT ASIA for suitability in sports construction
